Now available:
Allplan Engineering Civil 2018

Allplan Engineering
Raise your level

Allplan Engineering is the ultimate BIM solution for civil engineers and structural draftsmen designing bridges and heavy civil projects. Concrete structures with complex geometry, can be fully modeled, reinforced and detailed quickly and efficiently.
Speed up your work:

> Limitless modeling of any shapes
> Rapidly reinforce complex structures
> Freely definable longitudinal and transverse sections

Free Trial

Buy Allplan Engineering

Play the video

Allplan Engineering Civil

Allplan Engineering Civil is a powerful BIM tool that is optimized to the work processes of construction engineers within infrastructure construction. Due to a direct connection to the cloud-based BIM platform Allplan Bimplus, Allplan Engineering Civil is a complete BIM solution (up to BIM level 3). The software helps you to reduce planning and construction times and comply with cost frameworks.

The basis is a virtual model from which shell and reinforcement plans are generated with sections, views and visualizations as well as quantity determinations and bending schedules. The model also serves as the basis for structural calculations. Allplan Engineering Civil simplifies and accelerates planning and construction, reduces sources of errors and leads to a better common understanding of all those involved in the project.

Features 2018

All advantages of Allplan Engineering Civil at a glance

BIM-aided design

Allplan enables you to build virtually first then in reality, indicating any errors and conflicts early even during the design phase, avoiding delays in construction.

Seamless design process

Allplan supports the entire design process in a single system – from the initial draft right through to the final general arrangement and reinforcement drawings.

CAD and structural analysis

Structural/structural-analysis models and surveying results can be exchanged with FRILO Statik, SCIA Engineer, and other systems.

Diverse areas of use

Allplan Engineering is suitable for all types of construction projects - from small to highly complex, and for both buildings and civil engineering constructions.

Modeling without limits

The powerful Parasolid modeling kernel from Siemens gives you greater freedom when creating 3D models while also increasing precision and performance.

Reinforcement at the highest level

An integrated 3D model, complete with reinforcement, fixtures, and if necessary tendons, provides the highest possible design reliability and clarity.

Associative views

All changes are carried out once and then automatically transferred to all the drawings. This reduces errors and saves you time.

Impressive design documents

The powerful layout and design tools enable you to create high-quality design documents that make the value of your work clearly visible.

Smooth data exchange

To ensure smooth reliable data exchange with planning partners, the software includes high-quality interfaces with all conventional exchange formats, including DWG, DXF, DGN, IFC4, and PDF.

Optimized teamwork

With Allplan, you can collaborate on a project within an office and also across multiple locations. Together with the cloud-based platform Bimplus and Allplan Share, the multidisciplinary coordination of BIM models becomes reality.

Rapid productivity

A modern and intuitive user interface facilitates role and task based working enabling you to rapidly learn and become more productive.

4K/UHD

Allplan is also ideal for use on particularly powerful, high-resolution monitors (4K/UHD monitors with 3840 x 2160 pixels and more).

Options for Allplan Engineering Civil

Allplan Share

With "Allplan Share" you benefit from a direct collaboration with planning partners around the world with one and the same Allplan data. It is based on the BIM platform Allplan Bimplus and also allows the direct connection to other tools via the open API.

Allplan Share

Allplan Environment

In combination with Allplan Architecture or Allplan Engineering, building construction and civil engineering works can be efficiently planned while taking into account the real terrain, the urban development environment and the surrounding road network.

Data sheet

Allplan Workgroup Manager

Allplan Workgroup Manager assumes the organization of CAD work stations in local networks (LAN) as well as via Internet. It creates clear synergy effects in medium-sized and large planning and construction firms.


Data Sheet

Allplan License Server

Allplan License Server provides effective management and optimum use of your licenses. The license server allows secure access to licenses in the corporate network, while offering flexible usage for licenses outside of the office.

Data sheet

Allplan Bridge

Allplan Bridge is a powerful BIM solution for parametric modeling of bridges. The parametric 3D model offers an unprecedented level of user friendliness and flexibility, saving significant design time.


Allplan Bridge

ALLPLAN Services

Allplan Support: As a member of our Allplan Serviceplus network, you always work with the latest version and also efficiently exploit all the options of your software. Wether you are an administrator, architect, office manager or managing director, our support teams respond to your questions efficiently, comprehensively and professionally.

Allplan Forum: With our international service portal - Allplan Connect, you can take advantage of a global Allplan community. Join the experts today!

References

To all references

The Queensferry Crossing, Edinburgh in Scotland

The Queensferry Crossing near Edinburgh in Scotland is a cablestayed bridge with three pylons over 200 m in height. It is one of the largest infrastructure projects in Europe and benefitted from ultramodern reinforcement planning in 3D thanks to the engineers from Leonhardt, Andrä und Partner (LAP) and Allplan Engineering.

Transport Scotland’s consultants from the Jacobs Arup joint venture were not given an easy task in developing a concept for the new bridge. The bridge has to be an equal counterpart to the world cultural heritage of the "Forth Bridge."...

Read the full story

Gotthard Base Tunnel, Switzerland

The scheduled commissioning on December 11, 2016, marked the end of the project of the century – the Gotthard Base Tunnel – after nearly 20 years of building time. Its route length of 57 kilometers through the Saint-Gotthard Massif between Erstfeld and Bodio makes the Gotthard Base Tunnel the longest rail tunnel in the world.

The entire base tunnel, including cross-passages and multifunction stations, is double-walled. After the excavation support, a seal and an insituconcrete tunnel lining were installed. In the Erstfeld and Amsteg sections, the contractor used three formwork units, each with two 10-meterlong formwork carriages, for the cladding and tunnel lining...

Read the full story

Renowned companies put their trust in ALLPLAN

Satisfied customers are the best proof of the reliability and quality of a company and its products. Our reference reports are a testament to our software’s capabilities.

Try it for free

Allplan Engineering is the ultimate BIM solution for civil engineers and structural draftsmen designing bridges and heavy civil projects. Concrete structures with complex geometry, can be fully modeled, reinforced and detailed quickly and efficiently. Speed up your work:

  • Limitless modeling of any shapes
  • Rapidly reinforce complex structures
  • Freely definable longitudinal and transverse sections

Test the full version of Allplan Engineering for 30 days free of charge and with no obligation. Simply download the software and experience all the advantages for yourself.


DOWNLOAD NOW



*In a survey to 1,006 Allplan customers and prospects, we asked “Would you recommend Allplan to others?” and 96% answered “Yes”. Survey carried out in October and November 2016.
